SANS 1882:2003 | Permit nr:8101/12893
PRODUCT CODES:
COVER: CO113N00BK
FRAME: FR112BK
NOTE: Frames are also sold separately.
| DESCRIPTION: | Tyoe 8 Polymer gully grating and frame to SABS specification Sans 1882/1882 |
| DIMENSIONS: | 570 x 400mm – see drawings for more details |
| WEIGHT: | Frame 25.4kg ,Grating 22kg |
| FORCE: | 135kn |
| USAGE: | Stormwater and roads |
| DUTY CLASS: | Heavy duty |
| OPTIONAL: | |
| VARIATIONS: | Cover and Frame for new installations. Replacement covers for cast iron (stolen) |
| COLOURS: | As per customer requirements |
| COVER BRANDING: | As per customer requirements |
| CURRENT USERS: | All Municipals and Civils |
COVER: Type 8A |
    |
FRAME: Type 8A |
    |
